21700 3.6V 5000mAh消殺設備電池
產品編號：08DQ0034-02T
標稱電壓：25.2V
標稱容量：29400mAh
電池尺寸：213*181.5*88.5mm (Max)
充電溫度：0～45℃
放電溫度：-20 ~ 55 ℃
應用領域：其他
瀏覽次數：0次
產品詳情
Product number: 08DQ0034-02T
Cell model: LR21700/5000mah /3.60V
Specification: 21700-7S6P-29.4 AH-25.2V
Product size: 213*181.5*88.5mm (Max)
Nominal voltage: 25.2V
Nominal capacity: 29.4Ah
Charging voltage: 29.4V
Charging current: ≤ 8.82A
Discharge current: ≤20A
Discharge cut-off voltage: 19.6V
Finished product internal resistance: ≤150mΩ
Battery weight: 4.2kg
Charging temperature: 0 ~ 45℃
Discharge temperature: -20 ~ 55 ℃
Storage temperature: -20~+50℃ (less than 1 month) -20~ 40 ℃(less than 3 months); -20~+20℃ (less than 12 months)
Battery packaging: PVC heat shrinkable film packaging + plastic shell (provided by customers)
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, etc.
Application: disinfection equipment
Product Features
1.Blue PVC heat shrinkable film package is simple, reliable and easy to be installed.
2.Output terminal: Adopt the output mode of GB UL wire to increase conductive reliability.
3.Battery protection management: Adopt imported well-known protection chips with good stability, high precision monitoring and precise control, to eliminate safety risks to the maximum.
4.The battery pack has good safety, nice discharge performance and long cycle life.
5.The battery pack has a long cycle life and conforms to the values of low-carbon, energy saving and environmental protection.
